热镀锌4G 5G WIFI信号单管通信塔天线单极塔

型号 : Support customization

种类 : 通信塔

原产地 : Hebei, China

品牌 : Yinghao

高 : 支持自定义

表面处理 : 热浸镀锌

吊装方法 : 手动

材料 : Q420B/Q355B/Q235B, Q420B/Q355B/Q235B

产品名称 : 通信塔

颜色 : 定制颜色

使用寿命 : 20-50岁

应用程序 : 通信塔

MOQ : 10 tonnes

Price : US$1,200/tonnes 10-99 tonnes

Contact Now

Product Description

Radar tower is the 1 kind of building used to install radar equipment, usually used in meteorology, military, aviation and other fields. The height and structure of the radar tower need to be determined according to the specific radar model and use requirements.In the meteorological field, radar towers are often used to install weather radars for observing weather and meteorological parameters. The height and position of the radar tower need to be determined according to the observation needs and terrain conditions to ensure that the radar can cover the required observation area.
In the military field, radar towers are often used to install anti-aircraft radars for detecting and tracking enemy targets. The
height and position of the radar tower need to be determined according to the operational needs and terrain conditions to ensure that the radar can cover the required combat area. In aviation, radar towers are often used to install air traffic control radars for monitoring and controlling air traffic. The height and location of the radar towers need to be determined based on air traffic control needs and terrain conditions to ensure that the radar can cover the required control area.

Tower type			Self-supporting communication towers
Height range			15m~100m (customized according to needs)
Tower cross-section			regular quadrilateral or equilateral triangle
Design life			Static load
Static load			antenna Platforms Feeder ≤ 500 to 1000KG
Wind pressure			wind pressure resistance design up to 30m/s (corresponding to 12 typhoons)
Seismic resistance			8 intensity (GB 50011 standard)
Main material			ASTM Gr60/ASTM Gr50 或 S355JR/ASTM A36 或 S235JR
Connector			8.8 grade high-strength bolt (tensile strength≥ 1040MPa)
Anti-corrosion process			hot-dip galvanized (zinc layer thickness≥85μm)Fluorocarbon spraying (C5-M grade anti-corrosion)
Temperature range			-50°C~ 70°C
Humidity range			98% RH (non-condensing)
Salt Spray Resistance			≥ 3000 （ASTM B117 ）
Lightning protection level			first-class lightning protection (ground resistance≤4Ω, IEC 62305 standard)

Civil Aviation, Military Tower, Weather & Meteorological Radar Tower,Airport Radar Tower

Creative radar towers caters for heights up to 80m, constructed using a selection of tubular and angular members or combined. This provides the flexibility of global manufacture to facilitate the local sourcing of materials.

Specification

item	value
Model Number	Support customization
Type	communication tower
Brand Name	Yinghao
Place of Origin	China
	Hebei
Height	Support customization
Surface Treatment	hot dip galvanizing
Lifting method	Manual
Material	Q420B/Q355B/Q235B
Material	Q420B/Q355B/Q235B
Product name	communication tower
Color	Customized Color
Service life	20-50 Years
Application	Communication Tower
